Key features：

■ 10-inch 50-core paper cone combination woofer

■ Adopts 44-core compressed tweeter

■ The cabinet is made of 15 mm plywood, and the surface is treated with black wear-resistant painting

■ 70° x 100° coverage angle design with uniform and smooth axial and off-axis response

■ Avant-garde appearance, solid steel protective iron mesh

■ Precisely designed crossover optimizes frequency response

■ Rotatable BFAUDIO logo for easy vertical or horizontal installation

■ Multiple M8 threaded suspension points are designed to meet the application needs of using a variety of suspensions

■ KTV, nightclubs, clubs and other entertainment venues sound reinforcement

Product Parameters：

System type: 10-inch, 2-way, low-frequency reflex

Frequency range (-10dB): 54Hz-20KHz

Frequency response (±3dB): 77Hz-18KHz

Sensitivity (1w@1m): 96dB

Rated impedance: 8 ohms

Maximum SPL output: 120dB

Rated input power: 300W

Dispersion Angle: 70°X100(HxV)

Size(HxWxD): 533mm*300mm*309mm

Net weight: 17.5Kg
